HONEYWELL VC6831MS6111/U 1-inch Sweat Linear Flow Valve

Product Description

The HONEYWELL VC6831MS6111/U is a 1-inch sweat linear flow valve. This valve is suitable for controlling systems like central heating and cooling, fan coil units, radiators, and convectors. It can be operated by low or line voltage controllers, including room thermostats and flow switches. The valve has a 3-way body pattern and a flow capacity of 6.6 Cv. The actuator operates on a 24 Vac floating control signal.

• Operable with various controllers including room thermostats.
• Minimal actuator power consumption.
• Installation does not require draining the system.

Product Highlights

This valve is efficient for two-way or three-way configurations. It is designed for ease of use and reliable control in heating and cooling applications.

Product Information

Standard Information

• Manufacturer: HONEYWELL
• Part Number: VC6831MS6111/U

Technical Specifications

• Size: 1 inch
• Ambient Temperature: 32 to 140 degrees Fahrenheit
• Position: Normally Closed
• Actuator Type: Floating
• Control Signal: 24 Vac Floating
• Input Voltage: 24V
• Timing: 120 Seconds
• Body Pattern: 3-Way
• Connection Type: Sweat
• Flow Capacity (Cv): 6.6
