Honeywell VBN2GSPX6100 2-Way Ball Valve

Product Description

The Honeywell VBN2GSPX6100 is a 2-way ball valve that is built to manage water flow effectively. This valve features a brass trim and is compatible with modulating floating twenty-four VAC fail-safe actuators. The valve is constructed from forged brass, providing reliability and durability in various settings.

• Designed for hot or chilled water applications
• Compatible with up to fifty percent glycol solutions
• Offers Cv ratings similar to standard globe valves

Product Highlights

This valve is best for controlling flow in HVAC systems and plumbing applications, ensuring precise management of water temperature and pressure levels.

Product Information

Standard Information

• Manufacturer: Honeywell
• MPN: VBN2GSPX6100

Technical Specifications

• Connection: NPT
• Cv: 101 CV
• Trim Material: Brass
• Valve Pattern: 2-way
• Size: 2-1/2 inches
• Control Signal: Analog, Floating
• Flow Characteristic: Two-way: Equal percentage, Linear for full port models
• Leakage Rating: ANSI Class IV (0.01% of Cv)
• Maximum Closeoff Pressure: Two-way 1/2 inch and 3/4 inch: 130 psid, Two-way 1 inch to 3 inches: 100 psid
• Media Compatibility: Hot or chilled water, up to 50% glycol
• Media Temperature Range: -22°F to 250°F
• Compatible Actuators: Any Honeywell or Kele 44 in-lb actuators
• Pressure Rating: 360 psig @ 250°F
• Warranty: 5 years
