Honeywell VBN2G1PX6200 Ball Valve Assembly, 2 Way, 2-1/2 in NPT

Product Description

The Honeywell VBN2G1PX6200 is a two-way ball valve assembly designed for HVAC systems. It features a two and one-half inch NPT connection, making it suitable for various applications. This valve supports modulating and floating control, providing flexibility in your system setup.

• Characterized control valve rated at 202 Cv.
• Nickel chrome plated brass construction.
• Fail-safe open operation with direct coupled actuator.

Product Highlights

This valve is ideal for controlling flow in heating and cooling systems, providing reliable performance for hot and chilled water with glycol solutions.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: VBN2G1PX6200

Technical Specifications

• Housing: NEMA 2, IP54
• Service: Hot and chilled water with glycol solutions up to fifty percent
• Power Consumption: 5 VA
• Shaft Adapter Type: Self-centering clamping
• Flow Characteristic: Equal percentage
• Operating Conditions: -40 F to 150 F (-40 C to 65 C)
• Maximum Safe Operating Rating: 361 psi
