Honeywell VBN2DKPX7102 Control Ball Valve with Electric Actuator

Product Description

The Honeywell VBN2DKPX7102 is a reliable 2-way control ball valve equipped with an electric actuator. This valve is ideal for managing hot and chilled water, allowing up to fifty percent glycol solutions in HVAC installations. Its construction includes 1-1/4 inch NPT connections and brass trim for enhanced durability.

• 1-1/4 inch NPT connections for easy installation
• Flow coefficient of 14.9 for effective flow management
• Configured for two-position control and fail-safe operation

Product Highlights

This product is designed for efficient and precise control in HVAC systems.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBN2DKPX7102

Technical Specifications

• Control Valves Type: Ball Valve
• Connection: NPT
• Size: 1-1/4 inches
• Cv: 14.9 CV
• Trim Material: Brass
• Pattern: 2-way
• Control Signal: Two Position
• Body Pattern: Two-way and three-way
• Flow Characteristic: Equal percentage for models with parabolic insert
• Leakage Rating: ANSI Class IV (0.01% of Cv)
• Materials Of Construction: Forged brass body, nickel-plated brass ball and stem, EPDM o-rings
• Media Compatibility: Hot or chilled water, up to 50% glycol
• Media Temperature Range: -22°F to 250°F
• Pressure Rating: 360 psig @ 250°F
• Operating Temperature: -5°F to 140°F with MN actuators, -40°F to 150°F with MS actuators
