Honeywell VBN2CMPXC002 Control Ball Valve with Electric Actuator

Product Description

The Honeywell VBN2CMPXC002 is a one-inch, two-way control ball valve with an electric actuator, specifically designed for HVAC applications. This valve is ideal for managing the flow of hot or chilled water, as well as solutions containing up to fifty percent glycol. It features a plated brass trim and a DCA profile, ensuring durability and reliable operation. The valve operates on twenty-four VAC and includes two auxiliary switches housed in a NEMA three R enclosure.

• One-inch two-way control ball valve
• Compatible with chilled water, hot water, and up to fifty percent glycol mixtures
• NEMA three R enclosure for protection

Product Highlights

This control valve is essential for HVAC professionals seeking an efficient solution for fluid control in various systems.

Product Information

Standard Information

• Control Valves Type: Ball Valve
• Size: One inch NPT

Technical Specifications

• CV: 26.0
• Voltage: 24 VAC/VDC
• Operation: On/Off and Floating Point
• Actuator: Non-Spring Return - Fail In Place
• Torque: 44 in-lb
• Enclosure: NEMA 3R
• Close-Off: 100 psi
• Trim: Nickel Chrome Plated Brass
