Honeywell VBN2CMPX7202 Control Valve

Product Description

The Honeywell VBN2CMPX7202 is a 2-way control ball valve designed for HVAC systems. It is suitable for regulating the flow of hot and chilled water and can handle solutions with up to fifty percent glycol. This valve provides efficient control over heating, ventilation, and air conditioning processes.

• 1-inch NPT connection for easy integration
• Equal percentage flow characteristic for precise flow regulation
• Not suitable for oil, combustible gases, or steam

Product Highlights

The valve allows for two-position or modulating functions, ensuring flexibility in various applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VBN2CMPX7202

Technical Specifications

• Connection: NPT
• Cv: 26 CV
• Trim Material: Brass
• Pattern: 2-way
• Size: 1 inch
• Control Signal: Two Position
• Service: Hot and chilled water w/Glycol solutions up to 50%
• Flow Characteristic: Equal percentage
• Operating Temperature: -40 F to 149 F (-40 C to 65 C)
• Maximum Safe Operating Rating: 360 psi
• Power Consumption: 5 VA
• Operating Conditions: -40 F to 150 F (-40 C to 65 C)
• Housing: NEMA 2, IP54
