HONEYWELL VBN2CJPX7202 Control Valves

Product Description

The HONEYWELL VBN2CJPX7202 is a control ball valve ideal for HVAC systems. This valve efficiently manages hot and chilled water flow, supporting up to 50% glycol solutions. It features a parabolic flow insert allowing for Cv ratings comparable to globe valves. This design incorporates a two-way body pattern and a patented seat, which minimizes actuator torque requirements for operation.

• Parabolic flow insert for comparable Cv ratings
• Reduced torque needs for cost-effective actuator options
• Compatible with hot and chilled water and glycol blends

Product Highlights

Offering reliable control, the HONEYWELL VBN2CJPX7202 ensures efficient HVAC operation.

Product Information

Standard Information

• Connection: NPT
• Body Pressure Rating (maximum): 360 psi at 250°F

Technical Specifications

• Cv: 9 CV
• Trim Material: Brass
• Pattern: 2-way
• Size: 1 inch
• Control Signal: Two Position
• Medium Temperature Range: -22 to +250°F
