HONEYWELL VBN2AGPXB202 Control Ball Valve with Electric Actuator

Product Description

The HONEYWELL VBN2AGPXB202 is designed as a control ball valve with an electric actuator. This valve features a half-inch NPT connection and operates as a 2-way configuration. Key benefits include a flow coefficient of 2.6 Cv and plated brass trim, offering durability and efficiency. The valve supports modulating floating control and has a fail-closed function for reliability in various applications.

• 1/2 inch NPT connection
• 2-way valve with 2.6 Cv flow coefficient
• Modulating floating control with fail-closed design

Product Highlights

This valve operates on twenty-four volts alternating current, includes an auxiliary switch, and is encased in a NEMA 3R enclosure. This design provides environmental protection and reliable performance in different settings.

Product Information

Standard Information

• Brand: HONEYWELL
• MPN: VBN2AGPXB202

Technical Specifications

• Connection Size: 1/2 inch NPT
• Valve Type: 2-Way
• Cv: 2.6
• Trim Material: Plated Brass
• Control Type: Modulating Floating (Fail Closed)
• Actuator Voltage: 24 VAC
• Auxiliary Switch: 1
• Enclosure: NEMA 3R
