Honeywell VBN2AEPX9202 Control Valve

Product Description

The Honeywell VBN2AEPX9202 is a half-inch, two-way control ball valve ideal for regulating the flow of hot or chilled water in HVAC systems. It supports mixtures with up to fifty percent glycol and features a brass trim with an NPT connection. This valve showcases equal percentage flow characteristics similar to standard globe valves. It can be ordered with or without actuators, making it versatile for various applications.

• Nickel-chrome plated brass or 316 stainless steel ball and stem for durability.
• Removable manual operating handle for ease during installation or power failure.
• Compatible with Honeywell MVN and spring return low torque direct coupled actuators.

Product Highlights

Designed for flexibility, the VBN2AEPX9202 is suitable for cold, warm, and hot water systems in HVAC applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VBN2AEPX9202

Technical Specifications

• Connection: NPT
• Size: 1/2 in
• Cv: 1.3 CV
• Pattern: 2-way
• Control Signal: Two Position
• Supply Voltage (Nominal): 120 VAC
• Trim Material: Brass
• Media Compatibility: Hot or chilled water, up to 50% glycol
• Pressure Rating: 360 psig (2482 kPa) at 250°F (121°C)
• Leakage Rating: ANSI Class IV (0.01% of Cv)
• Media Temperature Range: -22°F to 250°F (-30°C to 121°C)
