HONEYWELL VBN2ADSXD002 Control Ball Valve with Electric Actuator

Product Description

The HONEYWELL VBN2ADSXD002 is a two-way control ball valve designed with an electric actuator. This valve features a half-inch NPT connection, ensuring easy installation. The flow coefficient is 0.68, which allows efficient fluid movement. It is made with stainless steel trim, providing durability and corrosion resistance.

• Operates on 24 VAC power
• NEMA 3R rated enclosure
• Includes two auxiliary switches

Product Highlights

This valve utilizes a DCA profile for optimal performance and offers a modulating floating operation, ensuring reliability. The fail-in-place functionality provides added safety during power losses.

Product Information

Standard Information

• Manufacturer: Honeywell
• Part Number: VBN2ADSXD002

Technical Specifications

• Model: P1911929
• Connection Size: 1/2 inch NPT
• Valve Type: 2-Way Control Ball Valve
• Flow Coefficient (Cv): 0.68
• Trim Material: Stainless Steel
• Profile: DCA
• Operation: Modulating Floating (Fail In Place)
• Input Voltage: 24 VAC
• Auxiliary Switches: 2
• Enclosure Rating: NEMA 3R
