Honeywell VBF3K41S0X Three-Way Flanged Actuated Control Ball Valve

Product Description

The Honeywell VBF3K41S0X is a three-way flanged ball valve suitable for regulating hot and chilled water in HVAC systems. This valve supports solutions containing up to fifty percent glycol and is ideal for use in closed-loop systems. It features a durable cast iron body, Teflon seat, and a 316 stainless steel stem. The valve is fully field configurable for either normally open or normally closed fail-safe modes.

• ANSI Class 125 flanged connections for easy installation.
• Includes a removable manual operating handle for manual control.
• Compatible with hot and chilled water, including up to 50% glycol solutions.

Product Highlights

This Honeywell valve is designed for seamless operation in HVAC applications, ensuring reliability in various fluid conditions.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBF3K41S0X

Technical Specifications

• Control Valves Type: Ball Valve
• Body Material: Cast Iron
• Seat Material: Teflon
• Stem Material: 316 Stainless Steel
• Connection Type: ANSI Class 125 Flanged
• Flow Capacity (Cv): 400
• Suitable Fluids: Hot and chilled water with glycol solutions up to 50%
• Operating Temperature: -22°F to 250°F (-30°C to 121°C)
• Close-off Pressure: Up to 70 psi
