Honeywell VBF3K11S0X 3-Way Flanged Control Ball Valve

Product Description

The Honeywell VBF3K11S0X is a 3-way flanged control ball valve suited for managing hot and chilled water, including up to 50% glycol solutions within closed-loop HVAC systems. Its robust construction features a cast iron body with a Teflon seat and a 316 stainless steel stem and ball.

• Removable manual operating handle for control in various situations.
• Field-configurable for normally open or normally closed positions.
• Four actuator mounting positions available.

Product Highlights

This valve is designed for two-position or modulating functions, providing equal percentage or linear flow characteristics.

Product Information

Standard Information

• Manufacturer: Honeywell
• Brand: Honeywell

Technical Specifications

• Flow Characteristic: Port A To AB: Equal Percentage / Port B To AB: Linear w/20% Reduced Flow Capacity
• Operating Temperature: -22 F To 250 F (-30 C To 121 C)
• Close Off Pressure: 70 psi
• Service: Hot And Chilled Water w/Glycol Solutions Up To 50%
