Honeywell VBF3JU1S0X Three-Way Flanged Control Ball Valve

Product Description

The Honeywell VBF3JU1S0X is a three-way flanged ball valve made for controlling hot and chilled water in HVAC systems. It can handle up to fifty percent glycol solutions. The valve features a cast iron body with a Teflon seat and a durable stainless steel stem. It is suitable for mixing or diverting applications and does not come with a pre-assembled actuator or weather enclosure. The valve connects with ANSI Class 125 flanged fittings.

• Valve sizes are available from four to six inches.
• Provides equal percentage or linear flow characteristics.
• Includes a removable manual operating handle.

Product Highlights

This valve is designed for reliability in both commercial and residential HVAC applications.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBF3JU1S0X

Technical Specifications

• Control Valves Type: Ball Valve
• Valve Size: Four inches
• Valve Piping: Three-Way
• Connection: Flanged
• CV: 152
• Close Off Pressure: Seventy psi
• NEMA Rating: Nema 2
• Linkage: Standard Flange Valve Linkage
• Trim: Stainless Steel
• Service: Hot and chilled water with glycol solutions up to fifty percent
• Flow Characteristic: Port A to AB: Equal Percentage / Port B to AB: Linear with Twenty Percent Reduced Flow Capacity
• Operating Temperature: Minus twenty-two degrees Fahrenheit to two hundred fifty degrees Fahrenheit (minus thirty degrees Celsius to one hundred twenty-one degrees Celsius)
• Assembly: Valve Only
