Honeywell VBF3JT1S0X 3-Way Flanged Control Ball Valve

Product Description

The Honeywell VBF3JT1S0X is a 3-way flanged ball valve engineered for controlling hot and chilled water along with up to 50% glycol solutions in closed-loop HVAC systems. It supports both two-position and modulating functions, making it versatile for various control applications.

• Constructed with a cast iron body for durability and long-lasting performance.
• Featuring a Teflon seat and a 316 stainless steel stem for efficient sealing and resistance to corrosion.
• Available in sizes from four to six inches, compatible with ANSI Class 125 flanged connections.

Product Highlights

This valve is ideal for both mixing and diverting applications, ensuring precise control in HVAC systems.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBF3JT1S0X

Technical Specifications

• Control Valves Type: Ball Valve
• Service: Hot and Chilled Water with Glycol Solutions up to 50%
• Flow Characteristic: Port A to AB: Equal Percentage / Port B to AB: Linear with 20% Reduced Flow Capacity
• Operating Temperature: -22 F to 250 F (-30 C to 121 C)
• Close Off Pressure: 70 psi
• Max Static Pressure: 240 psi
• Frequency: 50/60 Hz
• Power Supply: 24V
