HONEYWELL VBF3JS1S0X 3-Way Actuated Control Ball Valve

Product Description

The HONEYWELL VBF3JS1S0X is a three-way ball valve specifically designed for actuated control. This valve is built from durable cast iron with a stainless steel stem and is equipped with a Teflon seat for reliability. The valve supports ANSI Class 125 flanged connections and features a detachable manual operating handle. It can be configured for either normally open or normally closed fail-safe positions and allows for four different actuator mounting positions. This product is suitable for both hot and chilled water applications, as well as glycol solutions up to fifty percent concentration.

• 3-way design with a four-inch size and 91 Cv flow coefficient
• Includes a detachable manual operating handle
• Compatible with hot and chilled water, and glycol solutions up to fifty percent

Product Highlights

This ball valve is versatile for various applications in HVAC and plumbing, ensuring effective flow control.

Product Information

Standard Information

• Brand: Honeywell
• Control Valves Type: Ball Valve

Technical Specifications

• Valve Type: Ball Valve
• Number of Ways: 3-Way
• Inlet/Outlet Size: 4 inches
• Flow Coefficient (Cv): 91
• Body Material: Cast Iron
• Stem Material: 316 stainless steel
• Seat Material: Teflon
• Connection Type: ANSI Class 125 flanged
• Operating Temperature: -22°F to 250°F (-30°C to 121°C)
• Close Off Pressure: 70 psi
• Enclosure Rating: NEMA 3R (IP54) optional
