Honeywell VBF3J21S0X Three-Way Flanged Actuated Control Ball Valve

Product Description

The Honeywell VBF3J21S0X is a three-way flanged ball valve suitable for HVAC systems. It is designed to control hot and chilled water with glycol solutions up to fifty percent. This valve features a durable cast iron body, Teflon seat, and a sturdy 316 stainless steel stem.

• Suitable for hot and chilled water with glycol solutions up to fifty percent.
• Features a robust cast iron body and stainless steel stem.
• Offers equal percentage or linear flow characteristics.

Product Highlights

This valve provides flexibility in operation, allowing for field configuration to normally open or normally closed positions. It is available in sizes from four inches to six inches and comes with ANSI Class 125 flanged connections.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VBF3J21S0X

Technical Specifications

• Control Valves Type: Ball Valve
• Service: Hot and Chilled Water w/Glycol Solutions Up To 50%
• Flow Characteristic: Equal Percentage (Port A to AB), Linear (Port B to AB with 20% reduced flow capacity)
• Operating Temperature: -22 F To 250 F (-30 C To 121 C)
• Close Off Pressure: 70 psi
• Sizes: from 4 to 6 inch with ANSI Class 125 flanged connections
• Fail-safe position: Field configurable for normally open or normally closed
• Manual operation: Removable manual operating handle for control during power failure
• Valve ball and stem: 316 stainless steel
