Honeywell VBF2L51S0X Two-Way Flanged Actuated Control Ball Valve

Product Description

The Honeywell VBF2L51S0X is a two-way flanged ball valve used in HVAC systems to control hot and chilled water. It can handle up to fifty percent glycol solutions. This valve supports two-position and modulating functions. It features ANSI Class 125 flanged connections, ensuring a strong seal in your installation.

• Constructed with a 316 stainless steel stem for durability.
• Can be configured to be normally open or normally closed for flexibility.
• Includes a removable manual operating handle for manual control.

Product Highlights

Reliable control for HVAC applications, available for various actuator types.

Product Information

Standard Information

• Manufacturer: Honeywell
• Part Number: VBF2L51S0X

Technical Specifications

• Control Valve Type: Ball Valve
• Valve Type: 2-Way
• Connection Type: Flanged
• Size: six inches
• Cv Rating: 441
• ANSI Class: 125
• Max Static Pressure: 240 PSI
• Operating Temperature: -22 F to 250 F (-30 C to 121 C)
• Power Supply: 24V
• Frequency: 50/60 Hz
• Seat Material: Teflon
• Body Material: Cast Iron
• Stem Material: 316 Stainless Steel
• Leakage Class: ANSI Class IV
• Position: Normally Closed
