Honeywell VBF2L21S0C 2-Way Actuated Control Ball Valve

Product Description

The Honeywell VBF2L21S0C is a 2-way flanged ball valve suitable for controlling hot and chilled water containing up to 50% glycol in closed-loop HVAC systems. This valve features a durable cast iron body, a reliable Teflon seat, and a corrosion-resistant 316 stainless steel stem. It supports ANSI Class 125 flanged connections and can function in either normally open or normally closed positions. A manual operating handle is included to allow operator control during installation or in the event of a power failure.

• Suitable for use with hot and chilled water and glycol solutions up to 50%.
• Includes a removable manual operating handle for easy control.
• Meets ANSI Class IV leakage specification (0.01% of Cv).

Product Highlights

This control ball valve is designed for high performance in HVAC applications.

Product Information

Standard Information

• Brand: Honeywell
• Control Valves Type: Ball Valve

Technical Specifications

• Service: Hot and chilled water with glycol solutions up to 50%
• Flow Characteristic: Equal percentage, linear with full port
• Operating Temperature: -22 F to 250 F (-30 C to 121 C)
• Close Off Pressure: 70 psi
• Sizes: Four to six inches with ANSI Class 125 flanged connections
• Leakage Specification: ANSI Class IV leakage (0.01% of Cv)
