Honeywell VBF2J11SRB 2-Way Actuated Control Ball Valve

Product Description

The Honeywell VBF2J11SRB is a two-way actuated control ball valve designed for efficient flow management and isolation. The valve features a cast iron body and a Teflon seat, ensuring durability and reliability in various applications. This valve can handle both hot and chilled water, as well as glycol solutions up to fifty percent. It is available in sizes from four to six inches and is compatible with ANSI Class 125 flanged connections. The Honeywell VBF2J11SRB also comes with a removable manual operating handle and allows for field configuration of the fail-safe position.

• ANSI Class 125 flanged connections
• Removable manual operating handle included
• Field-configurable fail-safe position for operational flexibility

Product Highlights

The Honeywell VBF2J11SRB offers reliable flow control and flexibility in setup, making it suitable for HVAC systems, plumbing, and process control.

Product Information

Standard Information

• Manufacturer: Honeywell
• Brand: Honeywell

Technical Specifications

• Part Number: VBF2J11SRB
• Control Valves Type: Ball Valve
• Body Material: Flanged cast iron
• Seat Material: Teflon
• Stem Material: 316 stainless steel
• Sizes: Four to six inches
• Connections: ANSI Class 125 flanged
• Operating Handle: Removable manual
• Fail-safe Position: Field-configurable (normally open or normally closed)
• Enclosure: Optional NEMA 3R (IP54) rated
• Actuator Mounting Positions: Four
• Cv Choices: Ninety-one to six hundred fifty
• Leakage Specification: ANSI Class IV (0.01% of Cv)
• Service: Hot and chilled water with glycol solutions up to fifty percent
• Flow Characteristic: Equal percentage and linear with a full port
• Operating Temperature: Negative twenty-two F to two hundred fifty F (negative thirty C to one hundred twenty-one C)
• Close Off Pressure: Seventy psi
