Honeywell V5013B1003 Three-Way Flanged Globe Valve 63 Cv

Product Description

The Honeywell V5013B1003 is a three-way flanged globe valve known for its reliable flow control. This valve is designed to handle steam and water applications, ensuring precise performance.

• Three-way mixing globe valve with 2-1/2 inches flanged connection.
• 63 Cv capacity for efficient flow management.
• Suitable for chilled or hot water systems.

Product Highlights

The Honeywell V5013B1003 valve is crafted for durability and efficiency. Its cast iron body and stainless steel stem ensure long-lasting operation in demanding environments.

Product Information

Standard Information

• Brand: Honeywell
• MPN: V5013B1003

Technical Specifications

• Model: V5013B
• Valve Size: 2-1/2 inches
• Valve Connection: Flanged
• Piping Configuration: Three-Way
• Body Material: Cast Iron
• Valve Application: Steam, Water
• Max Pressure: 125 psi WOG
• Flow Capacity (Cv): 63
• Weight: 58.90 lbs
• Valve Action: Mixing, stem up increases B to AB flow
• Fluid Temperature Range: 40 F to 250 F
• Max Pressure Differential: 20 psi
