Honeywell V5011N1081/U 2-Way Globe Valve, Female Npt, 29 CV, 1-1/2 Pipe Size

Product Description

The Honeywell V5011N1081/U is a two-way globe valve designed for controlling steam, water, and glycol solutions. The valve operates efficiently in heating and cooling systems. Its construction allows for both two-position and modulating control, making it versatile for various applications.

• Suitable for fluid control in HVAC systems
• Direct and reverse acting features
• Maximum safe operating pressure of 217 psi

Product Highlights

This valve is ideal for use in commercial applications, providing reliable performance in challenging environments.

Product Information

Standard Information

• Manufacturer: Honeywell
• Model: V5011N1081/U

Technical Specifications

• Dimensions: Seven and one-eighth inches high x four and three-fourths inches wide x one and thirteen-sixteenths inches deep
• Maximum Safe Operating Pressure: 217 psi at two hundred forty-eight degrees Fahrenheit
• Pipe Size: One and one-half inches
• Capacity: 29 CV
• Materials: Red brass body, stainless steel seat and stem
• Controlled Fluid: Chilled or hot water with up to fifty percent glycol; not for use with steam
