Honeywell V5011G1129U Globe Valve 2 Way 3 in 100 Cv

Product Description

The Honeywell V5011G1129U is a globe valve designed for two-position or modulating control of steam, water, and glycol solutions in HVAC systems. This valve is suitable for heating or cooling applications, with a pipe size of three inches and a capacity of 100 Cv.

• Size range available from one half inch to six inches
• Stainless steel stem resists corrosion
• Designed for high pressure steam applications

Product Highlights

This valve provides reliable performance in commercial heating and cooling systems.

Product Information

Standard Information

• Brand: Honeywell
• Valve Type: Globe Valve

Technical Specifications

• Service: Steam, water, and glycol solutions up to 50% concentration
• Close-Off Pressure: 150 psi
• Flow Characteristic: Equal percentage
• Operating Temperature: 45 F to 250 F (4 C to 121 C)
• Dimensions: 9.25 inches high x 2.625 inches wide x 8.875 inches deep
• Connection Type: Female NPT
• Body Material: Red Brass
• Seat Material: Stainless Steel
