HONEYWELL V4046A1058/U Solenoid Valve 120V 1/8 inch NPT

Product Description

The HONEYWELL V4046A1058/U is a solenoid valve for controlling oil flow in heating systems. This valve is used primarily in domestic oil burners to ensure efficient fuel delivery.

• Provides on-off control of oil flow.
• Features a delayed opening for optimal fuel pump pressure.
• Constructed from durable aluminum.

Product Highlights

This solenoid valve enhances the performance of oil burner systems by minimizing post-burner drip.

Product Information

Standard Information

• Category: Valves
• Subcategory: Solenoid Valve

Technical Specifications

• MPN: V4046A1058/U
• Voltage: 120V
• Frequency: 60 Hz
• Pipe Size: 1/8 inch NPT
• Maximum Safe Operating Pressure: 150 psi
• Valve Opening Time: 3 to 8 seconds
• Valve Closing Time: 1 second max
• Coil: 120V, 60Hz
• Power Consumption: 8 W maximum at rated voltage
• Wiring Connection: Two 36 inch lead-wires; 1/2 inch conduit bushing
• Valve Pattern: Straight-through
• Valve Material: Aluminum
• Types of Oil: Use no heavier than No. 2 oil
