Honeywell TP972A2242 Pneumatic Thermostat Direct Cooling, Reverse He

Product Description

The Honeywell TP972A2242 is a pneumatic thermostat designed for controlling temperature in two-pipe heating and cooling systems. This device operates in the temperature range of sixty to ninety degrees Fahrenheit. It is ideal for industrial applications requiring precise temperature management.

• Operating pressure of 18 psi for heating and 13 psi for cooling.
• Includes a satin chrome cover with options for vertical or blank windows.
• Features a compact design, ideal for wall mounting.

Product Highlights

This thermostat provides reliable performance for HVAC systems.

Product Information

Standard Information

• Brand: Honeywell
• MPN: TP972A2242

Technical Specifications

• Temperature Range: 60°F to 90°F
• Throttling Range: 2°F to 10°F
• Dimensions: 3.25 inches high x 2 inches wide x 1.625 inches deep
• Weight: 1 pound
• Application: Wall Thermostat for heating and cooling
• Setpoint Temperature: Single
• Number of Pipes: 2
• Maximum Safe Operating Pressure: 25 psi
