Honeywell T775B2024/U Electronic Remote Controller with 4 Spdt Relays, Nema 4X, 1 Sensor Included

Product Description

The Honeywell T775B2024/U Electronic Remote Controller provides precise temperature control. Featuring 4 SPDT relays, a NEMA 4X enclosure, and one included sensor, this controller is ideal for various industrial applications.

• Graphical interface and large display
• Energy-saving scheduler
• Modulating high/low limit control option

Product Highlights

Save installation time with the intuitive graphical interface and easy programming. Control setback and disable output options to save energy. Protect equipment from freezing or overheating using the modulating limit control option.

Product Information

Standard Information

• Manufacturer: Honeywell
• Series: T775

Technical Specifications

• Control Range: -40 to 248 deg F
• Differential: 1 to 150 deg F
• Enclosure: NEMA 4X
• Includes: (1) T775-SENS-WR Sensor
• Number of Relay Inputs: 2
• Number of Relay Outputs: 4
• Sensing Bulb Size: 1/4 in Dia x 2 in L
• Sensor Type: 1097 Ohm PTC at 77 deg F
• Switch Action: SPDT
• Switch Type: Relay
• Voltage Rating: 24/120/240 VAC
• Dimensions: 4-13/32 in W x 2-15/16 in D x 8-5/32 in H
• Standards/Approvals: CE Certified, cULus Listed, C-Tick Approved, IP65 Approved, UL 60730-1
• Application: For applications requiring electronic accuracy and remote sensing of temperature
