Honeywell S8610M3009 Ignition Control Module for Gas Furnaces and Boilers

Product Description

Honeywell Ignition Control Module model S8610M3009 enhances reliability and efficiency in gas-fired furnaces and boilers. It is designed to control intermittent pilot ignition systems, ensuring safe and effective operation.

• Provides electronic control for optimal furnace performance.
• Ensures safety with flame monitoring and shutoff capabilities.
• Direct replacement for S86, S860, and S90 modules.

Product Highlights

This module aids in maintaining the proper operation of the heating appliance, reduces maintenance costs, and improves overall safety by maintaining proper combustion. Its compact design ensures easy installation.

Product Information

Standard Information

• Electrical Ratings: 24 Vac
• Frequency: 60 Hz
• Flame Failure Response Time: 2 seconds maximum
• Ignition System Type: Intermittent Pilot
• Ignition Trial Time: 90 seconds
• Max Valve Load: 1A Pilot, 2A Main @ 24Vac

Technical Specifications

• Temperature Range: -40 F to +175 F
• Typical Gas Control: VR8204, VR8304
• Type of Gas: Natural or LP
• Flame Sense: Single Rod
• Ignition Source: Internal high voltage spark generator
