Honeywell RRD8/U Retrofit Round Damper 24 VAC 8 Inch Diameter Replacement MPN

Product Description

The Honeywell RRD8/U Retrofit Round Damper is essential for managing airflow in HVAC systems. It supports a duct size of eight inches in diameter and features a robust construction with a frame thickness of eighteen gauge and a blade thickness of twenty gauge.

• Direct connection to damper shaft motor mount.
• Power open and power close functionality.
• Pre-installed black EPDM rubber gasket for improved sealing.

Product Highlights

This damper is designed for easy installation and effective air management in heating and cooling systems.

Product Information

Standard Information

• Brand: Honeywell
• MPN: RRD8/U

Technical Specifications

• Voltage Rating: 24 Volt AC 50/60 Hertz
• Motor Torque Rating: 35 Inch-Pound
• Ambient Temperature Rating: -40 to 122 Degrees F
• Pressure Drop: Less Than 0.05 Inch WC (Open)
• Motor Angular Rotation: 90 Degrees
• Leakage: 3.4 Percent at 0.5 Inch WC (Closed)
• Motor Timing: 90 Seconds
• Wires to Motor Terminal: 3
