Honeywell RP471A1002/U Snap-Acting Pneumatic Relay

Product Description

The Honeywell RP471A1002/U is a snap-acting pneumatic relay designed for wall or panel mounting. This four-port relay converts proportional air pressure changes into a two-position pressure signal. It is suitable for various HVAC control applications.

• Manually adjustable switching pressure
• Includes mounting clip for easy installation
• Constructed with molded plastic and neoprene diaphragms

Product Highlights

This relay allows for precise control in pneumatic systems and is ideal for use in commercial building controls.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: RP471A1002/U

Technical Specifications

• Application: Pneumatic, four-port, snap acting relay
• Dimensions: 1.5 inches diameter x 2.75 inches deep
• Maximum Safe Operating Pressure: 30 psi
• Temperature Range: 0°F to 140°F
• Operating Humidity Range: 5% to 95% RH
• Setpoint Range: Adjustable between 3 psi to 15 psi
• Nominal Switch Differential: 0.5 psi
• Includes: 1.5 inches mounting clip
