HONEYWELL RP470B1001/U LOCKOUT RELAY

Product Description

The HONEYWELL RP470B1001/U is a pneumatic selector relay designed for use in HVAC systems. It handles lockout, repeater, and input pressure applications. This three-port relay is suitable for various relay functions, ensuring reliability and efficiency in commercial building controls.

• Diaphragm-logic technology application.
• Mounting options available for wall, in-line, or panel.
• Features sharp-barb air connections for easy installation.

Product Highlights

This product is essential for anyone working with pneumatic systems, offering robust features and ease of use.

Product Information

Standard Information

• Application: Pneumatic three-port selector relay
• Manufacturer: HONEYWELL

Technical Specifications

• Dimensions: One and a half inches diameter x one inch deep
• Maximum Safe Operating Pressure: thirty psi (205 kPa)
• Temperature Range: zero to one hundred forty degrees Fahrenheit (negative eighteen to sixty degrees Celsius)
• Mounting Method: Wall, in-line, or panel
• Operating Humidity Range: five to ninety-five percent relative humidity
• Pressure Range: Input operating from zero to twenty psi (zero to 138 kPa)
• Air Connections: Barb fittings for five thirty-second inch (four mm) O.D. plastic tubing
• Capacity: Zero point zero thirty-nine scfm at one psi differential (eighteen mL/s at five kPa differential)
• Operation Types: Lockout, lower-of-two pressures, repeater relay
