Honeywell RM7823A1016/U Flame Switch Relay, 120 VAC

Product Description

The Honeywell RM7823A1016/U is a microprocessor-based flame switch relay designed to detect flames using rectification, ultraviolet, or infrared sources. It includes dual SPDT outputs for versatile applications in flame safeguard systems. This relay module works effectively with any 7800 series amplifier, ensuring reliable flame detection.

• Integrated flame switch for effective flame detection
• Compatible with existing Honeywell flame detectors
• Built-in indicators for power, flame, and alarm status

Product Highlights

This relay module enhances safety in combustion control systems by providing reliable flame detection capabilities.

Product Information

Standard Information

• Application: Flame Switch
• Minimum Order Quantity: 1

Technical Specifications

• Operating Conditions: -40 F to 140 F
• Required Components: Q7800A,B Universal Wiring Subbases. Compatible with various R7847 series amplifiers.
• Power Supply: 120 VAC
• Outputs: Two SPDT relays
• LED Indicators: Power, Flame, Alarm
• Memory: Nonvolatile memory for safety
• External Voltage Check Access: Yes
• Dimensions: Compact design for easy installation
