Honeywell PWT100/U Wet Differential Pressure Transmitter

Product Description

The Honeywell PWT100/U is a wet differential pressure transmitter that accurately measures and control differential pressure in various HVAC applications. It operates within a pressure range of zero to one hundred psid and offers multiple output options including 4-20 mA, 0-5 VDC, or 0-10 VDC. This transmitter is designed with a rugged die-cast enclosure that meets NEMA 4 standards, ensuring durability in challenging environments.

• 0-10, 0-20, 0-50, and 0-100 psid selectable pressure ranges.
• Field selectable output signals: 4-20 mA, 0-5 VDC, or 0-10 VDC.
• Jumper-selectable slow or fast response time for application flexibility.

Product Highlights

This pressure transmitter is ideal for monitoring pump differential pressure, chiller/boiler pressure drops, and other system differential pressure applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: PWT100/U

Technical Specifications

• Dimensions: 4 inches high x 5.64 inches wide x 2.13 inches deep
• Operating Humidity Range: 10 to 90% RH, non-condensing
• Voltage Supply: 12 to 30 VDC or 24 VAC
• Operating Temperature Range: 14 °F to 131 °F
• Pressure Range: 0-100, 0-50, 0-20, 0-10 psid
• Accuracy: 1% F.S. for 0-100, 0-50, 0-20 psid; 2% F.S. for 0-10 psid
• Connection Size: 1/8 inch NPT female
• Display: Yes
