Honeywell P658F1000/U Pneumatic Pressure To Electric Switch

Product Description

The Honeywell P658F1000/U is a pneumatic pressure to electric switch designed for various control applications in HVAC systems. This device converts a pneumatic signal into an electrical switching action. It can be used in HVAC control, making it essential for professionals in heating and cooling systems.

• SPDT switch with panel mount capability
• Adjustable pressure settings from two to seventeen psi
• Constructed with a neoprene diaphragm for durability

Product Highlights

This switch is ideal for surface or panel mounting and is factory calibrated for field adjustments. It is suitable for controlling pneumatic signals in multiple settings, including commercial buildings.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: P658F1000/U

Technical Specifications

• Application: Pneumatic / Electric Switch
• Dimensions: Three and a quarter inches high x two and seven eighths inches wide x one and a half inches deep
• Maximum Safe Operating Pressure: 30 psi
• Temperature Range: 40 F to 140 F
• Switch Type: Pneumatic/Electric Switch
• Setpoint Range: Field adjustable from two to seventeen psi
• Operating Humidity Range: 5 to 95% RH
• Electrical Connections: 1/4 inch quick-connect male terminals
