Honeywell MS8120A1205/U Direct Coupled Actuator 175 lb-in

Product Description

The Honeywell MS8120A1205/U is a direct coupled actuator designed for HVAC applications. This actuator provides a torque of 175 lb-in and operates at 24 VAC with a power rating of 40 VA. It features a spring return and includes two auxiliary switches, making it suitable for two-position control systems.

• Torque: 175 lb-in
• Operating Voltage: 24 VAC
• Auxiliary Switches: Two SPDT

Product Highlights

This actuator includes a self-centering shaft adapter, ensuring compatibility with various shaft sizes. It is UL listed for plenum-rated applications, ensuring safety and reliability in HVAC systems. The actuator is designed to operate efficiently in a temperature range of -40 F to 150 F.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MS8120A1205/U

Technical Specifications

• Power Consumption: 24 VAC
• Operating Temperature: -40 F to 150 F
• Electrical Connections: Field Wiring 14-22 AWG to screw terminals, located under the removable access cover
• Spring Return: Field selectable direction
• Access Cover: Yes, facilitates connectivity
• Construction: Metal housing
• End Limits: Built-in mechanical
