Honeywell MS8105A1130/U Direct Coupled Actuator 44 lb-in

Product Description

The Honeywell MS8105A1130/U is a direct coupled actuator designed for HVAC systems. This actuator offers a torque of 44 lb-in and operates on 24 VAC. It features a spring return mechanism and is suitable for use in various HVAC applications.

• Control signals: 2-position, SPST
• Mounting type: Direct Coupled
• Torque rating: 44 lb-in

Product Highlights

This actuator is ideal for controlling volume dampers or rotary valves. It can be mounted directly to the drive shaft or used remotely with added hardware. The compact design ensures easy installation in tight spaces.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS8105A1130/U

Technical Specifications

• Power Consumption: 24 VAC
• Auxiliary Switches: One SPDT
• Operating Temperature: -40 F to 150 F (-40 C to 65 C)
• Electrical Connections: Field wiring for 18 AWG to 14 AWG conductors
• Dimensions: 3-7/8 in W x 3-1/8 in D x 7 in H
• Material: Plastic
• Motor Timing: 45 seconds
• Includes: Mounting bracket, self-centering shaft adapter
