Honeywell MS7520A2205/U Direct Coupled Actuator 175 lb-in

Product Description

The Honeywell MS7520A2205/U is a direct coupled actuator designed for HVAC systems. It delivers a torque of 175 lb-in and operates on a power supply of 24 VAC. This actuator features a spring return mechanism and is suitable for applications requiring precise positioning. The actuator supports both floating and modulating control through various signal inputs. Its robust design ensures reliability in demanding environments.

• Torque rating: 175 lb-in
• Power supply: 24 VAC
• Field-selectable spring return direction

Product Highlights

This actuator is ideal for controlling dampers in heating, ventilation, and air conditioning systems. Its compact design allows for easy installation and maintenance.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS7520A2205/U

Technical Specifications

• Housing: Self-Centering Shaft Adapter (Shaft Coupling)
• Power Consumption: 24 VAC
• Auxiliary Switches: Two SPDT
• Operating Temperature: -40 F To 150 F (-40 C To 65 C)
• Electrical Connections: Field Wiring 14-22 AWG To Screw Terminals, Located Under The Removable Access Cover
