Honeywell MS7520A2007U Direct-Coupled Spring Return Actuator, 24Vac, 175 lb. Torque

Product Description

The Honeywell MS7520A2007/U Direct-Coupled Spring Return Actuator provides efficient control for HVAC systems. This actuator operates with a 24Vac power supply and offers 175 lb-in torque. Suitable for air dampers, air handlers, ventilation flaps, louvers, and ball valves.

• 24Vac power supply
• 175 lb-in torque rating
• Spring return functionality

Product Highlights

The Honeywell MS7520A2007/U actuator is designed for use in HVAC systems requiring precise control. It features a spring return mechanism for fail-safe operation and is compatible with various control systems including SPDT, floating, and modulating controls. The actuator includes an access cover for easy connectivity and has built-in mechanical end limits. It is UL listed and CE compliant, making it suitable for various applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS7520A2007/U

Technical Specifications

• Voltage Rating: 24Vac
• Torque Rating: 20 N-m
• Dimensions: 3.94 in W x 2.95 in D x 9.72 in H
• Material: Aluminum
• Mounting Type: Direct Coupled
• Motor Timing: 90 s
• Includes: Mounting Bracket, Self-Centering Shaft Adapter, 3 mm Crank
• Standards/Approvals: cUL C22.2 No.24-93, C-Tick N314, EMC/EC 108/EC, IEC 60730-1, Low Voltage Directive 95/EC, UL 873
