Honeywell MS7505A2030/U Direct-Coupled Spring Return Actuator 24Vac 44 lb. Torque

Product Description

The Honeywell MS7505A2030/U Direct-Coupled Spring Return Actuator with 44 lb. torque rating is designed for HVAC applications. It operates within a temperature range of -40 degrees to 149 degrees Fahrenheit and runs on 24Vac. This actuator is suitable for controlling air dampers, ventilation flaps, and more.

• Direct-coupled spring return actuator
• 44 lb. torque rating
• Suitable for air dampers and ventilation flaps

Product Highlights

Honeywell's MS7505A2030/U actuator provides reliable control for HVAC systems with its spring return feature and a robust torque rating. It is built for low voltage systems and offers different control options.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS7505A2030/U

Technical Specifications

• Type: Spring Return Floating
• Includes: Mounting Bracket, Self-Centering Shaft Adapter
• Material: Plastic
• Dimensions: 3-7/8 in W x 3-1/8 in D x 7 in H
• Application: HVAC Applications
• Motor Timing: 90 s
• Mounting Type: Direct Coupled
• Torque Rating: 44 in-lb
• Voltage Rating: 24 VAC
• Domestic/Import: Import
• Standards/Approvals: CE EMC/EC 108, Certification Low Voltage Directive 95/EC, IEC 60730-1, C-Tick N314, cUL C22.2 No 24-93
• Manufacturer Part Number: MS7505A2030/U
