Honeywell MS4120A1209/U Direct Coupled Actuator 175 lb-in

Product Description

The Honeywell MS4120A1209/U is a direct coupled actuator rated for torque up to 175 lb-in. This actuator operates on a voltage range of one hundred to two hundred fifty VAC. It features a spring return and is designed for reliable two-position control.

• Self-centering shaft adapter for various shaft sizes.
• Compatible with Sylk-enabled models for advanced connectivity.
• UL listed and plenum rated to meet safety standards.

Product Highlights

This actuator is robustly built with a metal housing and integrated mechanical end limits.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS4120A1209/U

Technical Specifications

• Power Consumption: 100-250 VAC
• Auxiliary Switches: Two SPDT
• Operating Temperature: -40 F to 150 F (-40 C to 65 C)
• Electrical Connections: Field wiring 14-22 AWG
• Dimensions: 3.94 in W x 2.95 in D x 9.72 in H
• Material: Aluminum
• Torque Rating: 175 lb-in
• Mounting Type: Direct Coupled
