Product Description
The Honeywell MS4103A1130/U is a direct coupled actuator designed for precise control in HVAC systems. It operates at a voltage range of one hundred to two hundred fifty VAC and is capable of delivering a torque rating of seven pound-inches. This actuator is suitable for applications involving volume control dampers, rotary valves such as ball or butterfly valves, and can be mounted directly to the drive shaft or remotely with accessory hardware.
- Spring return operation for reliable functionality.
- One SPDT auxiliary switch for additional control options.
- Operates effectively at temperatures from negative forty to one hundred fifty degrees Fahrenheit.
Product Highlights
Perfect for HVAC control applications, this actuator supports seamless integration into existing systems for effective energy management.
Product Information
Standard Information
-
Brand: Honeywell
-
MPN: MS4103A1130/U
Technical Specifications
-
Power Consumption: 100-250 VAC
-
Auxiliary Switches: One SPDT
-
Operating Temperature: -40 F To 150 F (-40 C To 65 C)
-
Electrical Connections: Field wiring 18 AWG to 14 AWG conductors and up to 2-14 AWG conductors to screw terminals, located under the removable access cover
-
Shipping Weight: 2 lbs
-
Torque Rating: 7 lb-in (3 Nm)
-
Style: Direct coupled
