Honeywell MS3105J3030/U Direct Coupled Actuator, 44 lb-in

Product Description

The Honeywell MS3105J3030/U is a direct coupled actuator designed for commercial building controls. It operates on twenty-four volts alternating current and is equipped with a spring return mechanism. This actuator applies torque of 44 lb-in, making it suitable for various applications, including volume control dampers and rotary valves.

• Spring return feature for reliable operation.
• Compatibility with both ball and butterfly valves.
• Field wiring options for flexible installation.

Product Highlights

This actuator supports advanced control functions, making it ideal for HVAC systems in commercial settings.

Product Information

Standard Information

• Brand: Honeywell
• MPN: MS3105J3030/U

Technical Specifications

• Power Consumption: 24 VAC
• Auxiliary Switches: One SPDT
• Operating Temperature: -40 F to 150 F (-40 C to 65 C)
• Electrical Connections: Field wiring 18 AWG to 14 AWG conductors
• Style: Dampers and damper actuators
• Housing: Self-centering shaft adapter
