Honeywell MP909D1441/U Pneumatic Damper Actuator 5 To 10 PSI 3 Stroke

Product Description

The Honeywell MP909D1441/U is a pneumatic damper actuator designed for reliable performance in HVAC systems. It operates within a pressure range of five to ten psi, providing efficient control for variable volume terminal units and small dampers. This actuator features a stroke length of three inches.

• Rugged aluminum body
• Low-friction shaft bearing
• Protected barb connector

Product Highlights

This actuator is suitable for both individual and sequence operation with other actuators, ensuring compatibility with a range of systems. Its robust design supports various mounting options.

Product Information

Standard Information

• Manufacturer: Honeywell
• Part Number: MP909D1441/U

Technical Specifications

• Maximum Operating Pressure: 30 psi
• Temperature Range: 50 F to 140 F
• Operating Humidity Range: 5 to 95% RH
• Stroke Length: 3 in.
• Diaphragm Effective Area: 3 sq in.
• Air Connections: Barbed fitting for 3/32 in. O.D. tubing
• Fail Safe Mode: Spring return
• Dimensions: 6 5/16 in. x 2 13/32 in.
