Honeywell MP909D1334/U Damper Actuator Spring Range with Ball Joint and Angle Bracket 5-10 PSI

Product Description

The Honeywell MP909D1334/U is a damper actuator designed for effective control in HVAC systems. This actuator is ideal for pneumatic proportional control within variable volume terminal units and small dampers. It operates within a pressure range of five to ten PSI and features a robust construction suitable for commercial applications.

• Pressure Range: 5 to 10 PSI
• Compatible with various competitors' products
• Includes mounting bracket with ball joint

Product Highlights

This actuator is engineered for reliable performance, providing precise control with durable components.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer: Honeywell

Technical Specifications

• Product Type: Spring Range with Ball Joint and Angle Bracket
• Operating Pressure: 5-10 PSI
• Shipping Weight: 2.000 LBS
• Dimensions: 6 5/16 inches long (adding 1 inch for shaft) x 2 13/32 inches diameter
• Max Safe Operating Pressure: 30 PSI
• Temperature Range: 50°F to 140°F
• Stroke: 2.4 inches
• Diaphragm Effective Area: 3 sq inches
• Air Connection: Barbed fitting for 3/32 inch O.D. tubing
