Honeywell MP909D1227/U Pneumatic Damper Actuator 5 To 10 psi

Product Description

The Honeywell MP909D1227/U is a pneumatic damper actuator designed for various ventilation tasks. It provides precise modulation in applications with a pressure range between five and ten psi. The actuator has a stroke length of two point four inches. Its barbed air connection fits a quarter-inch O.D. tubing, ensuring quick and secure installation.

• Pressure range: five to ten psi
• Stroke length: two point four inches
• Barbed air connection: quarter-inch O.D.

Product Highlights

This actuator operates effectively in commercial buildings, enhancing performance in pneumatic systems to control air distribution efficiently.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MP909D1227/U

Technical Specifications

• Stroke: 2.4 inches
• Air Connections: Barbed fitting for 3/32 O.D. tubing, 1/8 NPT
• Max Pressure (PSI): 30
• Operating Conditions: 50 F To 140 F (10 C to 60 C)
• Actuator Type: Damper
• Fail Safe Mode: Spring Return
• Diaphragm Effective Area: 3 sq in.
