Honeywell MP909D1201/U Pneumatic Damper Actuator 3-8 PSI

Product Description

The Honeywell MP909D1201/U is a pneumatic damper actuator designed for use in various HVAC applications. It operates within a pressure range of three to eight psi and features a stroke length of two point four inches. This actuator effectively controls the airflow in variable volume terminal units and small dampers.

• Low-friction shaft bearing for improved performance
• Protected barb connector to ensure secure connections
• Versatile mounting options for easy installation

Product Highlights

This product is used for pneumatic proportional control, making it highly compatible with various HVAC systems and other actuators.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MP909D1201/U

Technical Specifications

• Dimensions: Six and five-sixteenths inches long (add one inch for shaft) x two and thirteen thirty-seconds inches in diameter
• Maximum Safe Operating Pressure: Thirty psi
• Temperature Range: Fifty degrees Fahrenheit to one hundred forty degrees Fahrenheit
• Operating Humidity Range: Five to ninety-five percent relative humidity
• Stroke: Two point four inches
• Actuator Type: Damper with spring return fail-safe mode
• Air Connections: Barbed fitting for three thirty-seconds inch outer diameter tubing
