Honeywell MP516A1087/U Pneumatic Damper Actuator Spring Return

Product Description

The Honeywell MP516A1087/U is a pneumatic damper actuator designed for controlling dampers on unit ventilators. This actuator can be adjusted for various unit control cycles, enhancing its versatility.

• Constructed with strong zinc die castings.
• Hesitation feature for cycles that require a minimum percentage of outdoor air.
• Spring return functionality ensures reliable operation.

Product Highlights

This actuator excels in commercial building controls, particularly in HVAC applications. It provides reliable damper control and can be integrated into existing systems.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MP516A1087/U

Technical Specifications

• Operating Temperature Rating: -20 F to 160 F (-29 C to 71 C)
• Stroke Length: 2-1/8 inches to 2-1/2 inches
• Spring Range: 3 psi to 12 psi
• Dimensions: 5-1/8 inches high x 6-7/8 inches wide
• Maximum Safe Operating Pressure: 25 psi
• Operating Humidity Range: 5% to 95% RH
• Actuator Type: Damper
• Fail Safe Mode: Spring Return
