Honeywell MN7510A2209/U Direct Coupled Actuator 88 lb-in

Product Description

The Honeywell MN7510A2209/U is a direct coupled actuator with a torque capacity of eighty-eight pound-inches. This actuator operates at twenty-four VAC and is designed for applications requiring modulating control. Ideal for HVAC systems, it provides efficient performance for damper control.

• Non-spring return design
• Low power consumption at five VA
• Multiple connection options including 2-10 VDC and 4-20 mA

Product Highlights

The MN7510A2209/U actuator is compatible with various configurations and offers flexibility for installation in any orientation.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MN7510A2209/U

Technical Specifications

• Power Consumption: 24 VAC
• Auxiliary Switches: Two SPDT
• Operating Temperature: -5 F to 140 F (-20 C to 60 C)
• Electrical Connections: Field wiring 14-22 AWG to screw terminals, located under the removable access cover
• Housing: Self-centering shaft adapter (shaft coupling)
