Honeywell MN7510A2001/U Direct Coupled Actuator 88 lb-in

Product Description

The Honeywell MN7510A2001/U is a direct coupled actuator designed to control dampers efficiently. It operates at 24 VAC and has a rated torque of 88 pound-inches. This actuator features multiple electrical options including floating control and modulating operation. It is suitable for HVAC systems where accurate control of air flow is needed.

• Operating voltage: 24 VAC
• Power consumption rating of 5 VA
• Compatible with SPDT electrical connections

Product Highlights

This actuator has mechanical end limits for enhanced control and security. It supports a field-installable auxiliary switch. Additionally, the actuator is UL listed for safety and reliability.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: MN7510A2001/U

Technical Specifications

• Power Consumption: 24 VAC
• Auxiliary Switches: Two SPDT
• Operating Temperature: -5 F to 140 F (-20 C to 60 C)
• Electrical Connections: Field wiring 14-22 AWG to screw terminals
• Housing Style: Self-centering shaft adapter
• Orientation: Mountable in any orientation
