HONEYWELL M9484F4019 Modutrol IV Motor Series 90 75 lb-in Torque

Product Description

The Honeywell M9484F4019 is a Series 90 Modutrol IV motor designed for modulating proportional control in heating and cooling systems. This motor operates on twenty-four VAC and provides a torque of seventy-five lb-in. It is suitable for various flame safeguard firing rate applications and features a field-adjustable stroke ranging from ninety to one hundred sixty degrees with a running time of fifteen to thirty seconds.

• Non-spring return design makes it reliable for continuous operation.
• Includes two auxiliary switches for enhanced control.
• Equipped with an integral junction box that ensures NEMA 3 weather protection.

Product Highlights

This motor is ideal for commercial and industrial oil or gas burner systems, ensuring precise flame modulation.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Name: Honeywell

Technical Specifications

• Modutrol Series: M9484
• Torque: 75 lb-in
• Input Voltage: 24 VAC
• Control Signal: Proportional (135 ohm)
• Stroke: 90 to 160 degrees
• Stroke Running Time: 15 to 30 seconds
• Auxiliary Switch: 2 Auxiliary Switches
• Power Loss Action: Non-spring Return
• NEMA Rating: NEMA 3
• Operating Conditions: -40 F to 150 F (-40 C to 66 C)
• Crank Shaft: Double-ended, 3/8 in. square
• Weight: 6.81 lbs
