Honeywell M9185E4005 24V Spring Return Foot Mounted Actuator w/ Auxiliary Switch 135 Ohm 60 lb-in

Product Description

The Honeywell M9185E4005 is a 24V spring return foot mounted actuator designed for efficient control of dampers and valves. This actuator operates using a proportional control signal with a resistance of 135 Ohms. The device is built to provide reliability in HVAC applications.

• Integral junction box offers NEMA 3 weather protection.
• Field adjustable stroke ranging from ninety to one hundred sixty degrees.
• Can support additional external auxiliary switches.

Product Highlights

This actuator integrates easily into existing systems and provides precise control for HVAC professionals.

Product Information

Standard Information

• Application Type: Electric
• Fail Safe Mode: Spring Return

Technical Specifications

• Control Signal: Proportional
• Motor Shaft: Dual ended
• Stroke: Adjustable; ninety to one hundred sixty degrees, Symmetrical
• Torque Rating: Sixty lb-in
• Power Consumption: Twenty VA
• Electrical Connections: Quick Connect Terminals
• Shaft Dimensions: Zero point three seven five inches
• Shaft Shape: Square
• Mounting: Foot-mounted
• Dimensions: Six and seven sixteenths inches high x five and one half inches wide x eight and three quarters inches deep
• Temperature Range: Minus forty to one hundred fifty degrees Fahrenheit
• Deadweight Load on Shaft: Two hundred pounds (either end), three hundred pounds (combined)
• Nominal Timing: Thirty to sixty seconds
• Shaft Rotation: Clockwise
