Honeywell M9185E1019/U Modutrol IV Motor Spring Return

Product Description

The Honeywell M9185E1019/U Modutrol IV Motor is designed for HVAC applications requiring efficient control of dampers and valves. This motor operates on a twenty-four volt supply and provides a torque rating of sixty in-lbs. It is suitable for environments with temperatures ranging from minus forty degrees Fahrenheit to one hundred fifty degrees Fahrenheit.

• Integral junction box offers NEMA 3 weather protection when mounted upright.
• Quick-connect terminals simplify wiring connections.
• Field adjustable stroke allows for flexibility between ninety and one hundred sixty degrees.

Product Highlights

This motor has dual shafts and can easily adapt to existing setups.

Product Information

Standard Information

• Brand: Honeywell
• Part Number: M9185E1019/U

Technical Specifications

• Power Consumption: 20 VA
• Torque Rating: 60 in-lbs
• Operating Conditions: -40 F to 150 F
• Electrical Connections: Quick-Connect Terminals
• Auxiliary Switch: 1
